Smart Outlet (UK)

Product Code: YO515uk


Color: Smart Outlet (UK)

Related Products

Smart Power Control For A Smart Home

How Yoswit Smart Outlet Works


Comparison

Yoswit Smart Switch

  • UK / EU
  • Bluetooth

Schneider
(ULTI Ezinstall3)

Legrand
(Arteor/Adorne/Radiant)

  • US
  • Wifi

Leviton
(Decora)

LUTRON
(Maestro/Caseta)


Run Your Home from Your Phone

Mobile As Hub
Mobile As Hub
Voice Control
Voice Control
Mesh-like Network
Mesh-like Network
Remote Control
Remote Control
Room and Scenes
Away Detection
Away Detection
Schedule Timers
Schedule Timers
Password Protection
Password Protection
IFTTT
IFTTT

Bluetooth Version

We use Bluetooth 4.2 (also sometimes referred to as Bluetooth Low Energy or BLE) as the core processor of our products.

Compatible Devices

We support all Smart Ready products with our application installed. Please Click Here to get the growing list.

IOS Support

We support IOS 7.0 or above versions. Also, we have separate applications with different resolution for iPhone and iPad.

Android Support

We support Android 4.3 or above versions. It's the first Android version with Bluetooth Smart support which has just been released on Aug 2013.

General
Product Name Yoswit Smart Outlet
Model YO515uk
Revision V1
Compliance CE, FCC, RoHS
Manufacturer Designed by Yoswit in Hong Kong. Assembled in China.
Mechanical
Surface Materials V0 flame-resistant PC +ABS
Socket Type 86
Storage Conditions -20°C to 60°C
Operating Environment Indoors
Operating Temperature Range -10°C to 40°C
Ingress Protection (IP) 20
Electrical
Input Voltage AC100-240V
Frequency 50/60Hz Auto Detected at Power-Up
Resistive Load Current 13A
Inductive Load Current 5A
Standby Power <0.1 watt
Bluetooth
Product Compatibility Bluetooth Smart Ready products
Frequency 2.4GHz
Radio Transmission Power 0~5 dBm
Bluetooth Range Open area: >50m; indoor: 10-20m
Bluetooth Version Bluetooth 4.2

WARNING !

warning

Disconnect Power

To prevent severe shock or electrocution, always disconnect the power at the service panel before installation. Only licensed electricians should carry out the installation.


Basic Installation

1

Remove the old outlet and disconnect the wires, please make sure that there is about 5mm of bare wire exposing.

outlet_uk_step1

2

Insert a small, flat screwdriver in notches on wall plate and twist gently to pry from frame to remove wall plate.

outlet_uk_step2

3

Connect the wires to the outlet. Make sure that the wires are secure.

warning

Warning

To reduce risk of electrical shock, unit shall be properly grounded in accordance with local regulations or codes. Failure to connect the ground wire will result in an unsafe installation that could lead to personal injury.


4

Fasten the outlet on wall by placing the proper wall mount components.

outlet_uk_step4

5

Turn on the circuit breaker and connect to the power.


6

Test the outlet by tapping the power button of the outlet 2 to 3 times. The LED will be on/off.

outlet_uk_step6

7

Plug in your devices.

Warning

To reduce risk of electrical shock, please make sure the devices and the outlet are off.


8

Press the power button of the outlet and your devices on.


Installation complete.

Download the Yoswit App to your smart device and enjoy it now!

Yoswit will automatically detect the switch and add to your device list.

Download
Certification CE EMC CE LVD CE R&TTE FCC RoHS
User Manual Download
Data Sheet Download
Leaflet Download
Yoswit App
Yoswit App (Android Apk) Download
